  • 596 series - 1.0mm Pitch strip header SMT Type - Weitronic Enterprise Co., Ltd.

  • 596 series

    1.0mm Pitch strip header SMT Type


    596 SMT

Description

Technical data:
Insulator Material: High Temperature      Thermoplastic,UL 94V-0

Contact: 0.30 x 0.30mm

Contact  Material: copper alloy

Plating: Au or Sn over Nickle

Current Rating: 1 Amp

Insulator resistance: 500 Megohms min.

Dielectric withstanding: AC 500V for 1 Minute.

Operating Temperature: -40 ℃to + 105 ℃.

Max. processing Temp: 230 ℃ for 30-60 seconds.    260  ℃for 10 seconds.

Mates with: 597
